NEET Physics Friction Online Test Set A

1. The mass string system shown in the figure is in equilibrium. If the coefficient of friction between A and the table is 0.3, the frictional force on A is:

2.

3.

4.

5. A given object takes n times as much time to slide down a 45° rough incline as it takes to slide down a perfectly smooth 45° incline. The coefficient of friction between the object and the incline is

6. The two blocks, m = 10 kg and M = 50 kg are free to move as shown. The coefficient of static friction between the blocks is 0.5 and there is no friction between M and the ground. A minimum horizontal force F is applied to hold m against M that is equal to

7. A block A of mass 4 kg is placed on another block B of mass 5 kg, and the block B rests on a smooth horizontal table. If the minimum force that can be applied on A so that both the blocks move together is 12 N, the maximum force that can be applied to B for the blocks to move together will be

8. The retarding acceleration of 7.35 m s^–2 due to frictional force stops the car of mass 400 kg travelling on a road. The coefficient of friction between the tyre of the car and the road is

9.

10. A block of mass 0.1kg is held against a wall applying a horizontal force of 5 N on the block. If the coefficient of friction between the block and the wall is 0.5, the magnitude of the frictional force acting on the block is:

11.

12.

13. A block rests on a rough inclined plane making an angle of 30° with the horizontal. The coefficient of static friction between the block and the plane is 0.8. If the frictional force on the block is 10 N, the mass of the block (in kg) is
(take g = 10 m / s² )

14. A marble block of mass 2 kg lying on ice when given a velocity of 6 m/s is stopped by friction in 10 s. Then the coefficient of friction is (Take g = 10 ms^–2)

15. A body of mass 2 kg is placed on a horizontal surface having kinetic friction 0.4 and static friction 0.5. If the force applied on the body is 2.5 N, then the frictional force acting on the body will be [g = 10 ms^–2]

16.

17. A horizontal force of 10 N is necessary to just hold a block stationary against a wall. The coefficient of friction between the block and the wall is 0.2. The weight of the block is

18.

19. A conveyor belt is moving at a constant speed of 2m/s. A box is gently dropped on it. The coefficient of friction between them is μ = 0.5. The distance that the box will move relative to belt before coming to rest on it taking g = 10 ms^–2, is

20.

21.

22.

23. Select the incorrect statement(s) from the following.
I. Limiting friction is always greater than the kinetic friction.
II. Limiting friction is always less than the static friction.
III. Coefficient of static fiction is always greater than the coefficient of kinetic fiction

24. Which of the following statements about friction is true?

25. Select the incorrect statement(s) about static friction.
I. Static friction exists on its own.
II. In the absence of applied force static friction is maximum.
III. Static friction is equal and opposite to the applied force upto a certain limit.

26. It is difficult to move a cycle with brakes on because

27. When a box is in stationary position with respect to train moving with acceleration, then relative motion is opposed by the ...X.... Which provides the same acceleration to the box as that of the train, keeping it stationary relative to the train. Here, X refers to

28. If the applied force is doubled, then coefficient of friction is

29. The coefficient of static friction between two surfaces depends upon

30. Identify the correct statement from the following
